Deploying Active Directory Domain Services on Windows Server 2012 R2

Deploying Active Directory Domain Services 2012 R2

 clip_image001










   Guide 1.0
David Acevedo









Step By Step to deploy Active Directory Domain Services

  1. Open your Server Manager Dashboard

clip_image002

  1. Click on Manage then Add Roles and Features  it will appear the Wizard


 clip_image003
clip_image004

  1. Click Next

clip_image005

  1. Select Role-Based o feature-based installation and Next

clip_image006

  1. Select a server from the server pool and Next.
Note:    In my case is the DC01 but you can have multiple servers  add them the roles/features and you don’t need to access the remote servers. This helps you to consolidate administration.

clip_image007

  1. Select Active Directory Domain Services and all required features for ADDS click Add Features and Next.

clip_image008

  1. Next on Features Tab
  2. Next on AD DS

clip_image009

  1. Now Install  (I recommend to select the Auto Restart )

  1. Now you are Installing AD DS

clip_image010

clip_image011

  1. Now you need to promote this server to a domain controller

clip_image012

  1. Click on Promote this server to a domain controller

clip_image013

  1. In my scenario I will select Add a new forest and click Next

clip_image014

  1. Now you have to configure the Forest/domain functional level in my case will be Windows Server 2012 because my hierarchy is in 2012.

clip_image015

  1. Set the Password for the DSRM and click Next

clip_image016

  1. DNS Option click Next

  1. Additional Options verify the NetBIOS name assigned you always can change it.

clip_image017

  1. Paths  click Next

  1. Review Options click Next
    1. (at this point you can export this configuration to Power Shell and use for future installations)
clip_image018

  1. Prerequisites Check click Next

clip_image019

  1. Install you can always monitor progress on the Server Manager Dashboard by Clicking the Flag

clip_image020

clip_image021

  1. Results  the server will re-bounce  automatically

clip_image022

  1. Now you have Active Directory Domain Services 2012 R2  installed and configured.

clip_image023

clip_image024

clip_image025

clip_image026

clip_image027
  1. Thanks,
